| Amplifier program power | 800 W (LF) + 200 W (HF) Class D Bi-amplified |
| Analog input | Nominal: +8 dBu. Max: +20 dBu. Impedance: 20 kΩ Balanced |
| Audio networking | Dante™ audio networking input, 1 channel, 48kHz |
| Mains | Universal switch mode Power Supply 85-265 V / 45-65 Hz |
| Average current draw | 1.7 A (Heavy duty musical program) |
| SPL (1m) | 128 dB continuous, 131 dB peak |
| Built-in DSP | 64- bit processing unit. Includes factory presets |
| AD/DA converters | 24 bit – 48 kHz |
| Presets | FR_FLAT / FR_NEARFIELD / HPF90_FLAT / HPF90_NEARFIELD / SPEECH + 25 configurable user memories |
| Frequency response (-10 dB) | 53 Hz – 19 kHz |
| LF | 10″ neodymium woofer (3″ voice coil) |
| HF | 1 × 1.7″ HF polymer diaphragm, neodymium magnet compression driver |
| Directivity (H×V) | 50º to 100º (H) × 55º(V) |
| Dimensions (H×W×D) | 554 × 303 × 370 mm |
| Weight | 19 kg |
| Finish | Multilayer baltic birch plywood with high resistant black Polyurea® coating and protective rubber profiles |
| Grille | 1.5 mm steel with grey micro-foam cloth |
| Connectors | 1x XLR input / 1x XLR link / 1x AC PowerCon® input / 1x AC PowerCon® link / 1x EtherCon® RJ45 input / 1x EtherCon® RJ45 link |
